50m 2 Port USB 2.0 Cat. 6 Extender
The Extender features bidirectional Power over Cable (PoC) functionality, which provides additional flexibility. This allows power to be supplied alongside data through Cat.6 network cable in a point-to-point connection between the transmitter and receiver, meaning only a single power supply is required at the transmitter or receiver unit.
With robust metal housing and integrated mounting brackets this Extender is the ideal solution for industrial environments.
Lindy 50m 2 Port USB 2.0 Cat. 6 Extender
MPN:
43386
Low stock: 2
Price excluding VAT:
Exc Vat £83.33
Price including VAT:
Inc Vat £100.00
Shipping calculated at checkout.
Details
Key Features
- Extend 2 USB 2.0 ports up to 50m using low cost Cat.6 network cable (not included)
- Bi-directional PoC (Power over Cable) requires a power supply connection from only one side of the installation
- Supports USB 2.0 High Speed and USB 1.1 Full Speed / Low Speed
- Plug and Play installation
- 2 year warranty
Description
This Lindy USB 2.0 Cat.6 Extender can be used to extend the distance between two USB peripheral devices and the host computer by up to 50m. A standard, low cost Cat.6 network cable (not included) is used to bridge the connection between the transmitter and the receiver unit. For best performance and compatibility, we recommend the use of solid core patched cables.The Extender features bidirectional Power over Cable (PoC) functionality, which provides additional flexibility. This allows power to be supplied alongside data through Cat.6 network cable in a point-to-point connection between the transmitter and receiver, meaning only a single power supply is required at the transmitter or receiver unit.
With robust metal housing and integrated mounting brackets this Extender is the ideal solution for industrial environments.
Specifications
| Performance | |
|---|---|
| Plug and Play | Yes |
| Type | Network transmitter & receiver |
| Maximum transfer distance | 50 m |
| Data transfer rate | 480 Mbit/s |
| Cable types supported | Cat5e, Cat6 |
| Chipset | NS1021 |
| Ports & interfaces | |
| RJ-45 ports quantity (transmitter) | 1 |
| RJ-45 ports quantity (receiver) | 1 |
| DC-in jack | Yes |
| USB 2.0 ports quantity | 3 |
| Ethernet LAN (RJ-45) ports | 2 |
| RJ-45 output ports | 1 |
| RJ-45 input ports | 1 |
| Design | |
| Product colour | Black |
| Quantity per pack | 1 pc(s) |
| Power | |
| Input current | 2 A |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 125 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 90% |
| Weight & dimensions | |
| Transmitter width | 6.02 cm |
| Transmitter depth | 6.7 cm |
| Transmitter height | 2.37 cm |
| Transmitter weight | 195 g |
| Receiver width | 6.02 cm |
| Receiver depth | 6.7 cm |
| Receiver height | 2.6 cm |
| Receiver weight | 195 g |
| Packaging content | |
| AC adapter included | Yes |
| Manual | Yes |
| Cables included | USB |
| Sustainability | |
| Sustainability compliance | Yes |
| Technical details | |
| Plug and Play | Yes |
| Type | Network transmitter & receiver |
| Maximum transfer distance | 50 m |
| Data transfer rate | 480 Mbit/s |
| Cable types supported | Cat5e, Cat6 |
| Chipset | NS1021 |
| Sustainability compliance | Yes |
| Compliance certificates | CE, Federal Communications Commission (FCC), REACH, RoHS |
| Colour | |
| Product colour | Black |
| Certificates | |
| Compliance certificates | CE, Federal Communications Commission (FCC), REACH, RoHS |
