RG-RAP6260(H)-D Reyee AX6000 High-density Outdoor Directional Access Point
With a revolutionary combination of OFDMA and 1024QAM, the latest 802.11ax standard, the 160MHz band, and dual band 4x4 MU-MIMO, RG-RAP6260(H) wireless aggregation rate reaches 5.95Gbps.
Easily Add Extra Outdoor Wi-Fi with Reyee Mesh
Less wiring, more relaxing
Support Extra-Distance Access Point Deployment
With gigabit SFP port, the device supports up to 20km
transmission from datacenter with single mode fiber
Rock-solid in Harsh Environments
Adopts completely sealed, waterproof, dustproof, moisture proof and flame-retardant,
wind erosion protection,wide temperature range, and 4kV surge protection design.
Directional Coverage with Long Range
Built-in high gain antennas, supports full coverage.
Ruijie Networks RG-RAP6260(H)-D wireless access point 5950 Mbit/s White Power over Ethernet (PoE)
MPN:
RG-RAP6260(H)-D
In stock: 10
Price excluding VAT:
Exc Vat £228.76
Price including VAT:
Inc Vat £274.51
Shipping calculated at checkout.
Details
Key Features
- Ultra-fast 5.95 Gbit/s outdoor Wi-Fi 6, best-in-class Wi-Fi performance
- Easily adding extra outdoor Wi-Fi with Reyee mesh
- Long-distance deployment with optical ports
- IP68 rating, adapting to harsh environments
- Internet access with 2.5 Gbit/s uplink
Description
Best-in-class Wi-Fi PerformanceWith a revolutionary combination of OFDMA and 1024QAM, the latest 802.11ax standard, the 160MHz band, and dual band 4x4 MU-MIMO, RG-RAP6260(H) wireless aggregation rate reaches 5.95Gbps.
Easily Add Extra Outdoor Wi-Fi with Reyee Mesh
Less wiring, more relaxing
Support Extra-Distance Access Point Deployment
With gigabit SFP port, the device supports up to 20km
transmission from datacenter with single mode fiber
Rock-solid in Harsh Environments
Adopts completely sealed, waterproof, dustproof, moisture proof and flame-retardant,
wind erosion protection,wide temperature range, and 4kV surge protection design.
Directional Coverage with Long Range
Built-in high gain antennas, supports full coverage.
Specifications
| Data transmission | |
|---|---|
| Ethernet LAN data rates | 100,1000,2500 Mbit/s |
| Maximum data transfer rate | 5950 Mbit/s |
| Performance | |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Reset button | Yes |
| Spread spectrum method | OFDMA |
| Number of users | 130 user(s) |
| Web-based management | Yes |
| VLAN support | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Maximum outdoor range | 300 m |
| Ethernet LAN data rates | 100,1000,2500 Mbit/s |
| Maximum data transfer rate | 5950 Mbit/s |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Wireless LAN features | |
| Maximum outdoor range | 300 m |
| Network | |
| Spread spectrum method | OFDMA |
| Number of users | 130 user(s) |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Management features | |
| VLAN support | Yes |
| Web-based management | Yes |
| Features | |
| 6 GHz | No |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Spread spectrum method | OFDMA |
| Number of users | 130 user(s) |
| VLAN support | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Maximum outdoor range | 300 m |
| Ethernet LAN data rates | 100,1000,2500 Mbit/s |
| Maximum data transfer rate | 5950 Mbit/s |
| Dynamic Frequency Selection (DFS) | Yes |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Maximum data transfer rate (2.4 GHz) | 1148 Mbit/s |
| Maximum data transfer rate (5 GHz) | 4804 Mbit/s |
| BeamForming | Yes |
| Security | |
| Number of SSID supported | 8 |
| Security algorithms | SSID, WPA-PSK, WPA2-PSK |
| Protocols | |
| DHCP server | Yes |
| DHCP client | Yes |
| Ports & interfaces | |
| USB 2.0 ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 2 |
| DC-in jack | Yes |
| Power | |
| Power consumption (max) | 40 W |
| Power over Ethernet (PoE) | Yes |
| Input current | 1 A |
| DC voltage range | 48 V |
| Design | |
| International Protection (IP) code | IP68 |
| Placement | Pole, Wall |
| Product colour | White |
| Reset button | Yes |
| LED indicators | System |
| Antenna | |
| Antenna type | Internal |
| Antennas quantity | 8 |
| Antenna direction type | Directional |
| Technical details | |
| Reset button | Yes |
| Indication | |
| LED indicators | System |
| Software | |
| Dynamic Frequency Selection (DFS) | Yes |
| Weight & dimensions | |
| Width | 300 mm |
| Depth | 300 mm |
| Weight | 3.5 kg |
| Height | 75.5 mm |
| Package width | 395 mm |
| Package depth | 395 mm |
| Package height | 197 mm |
| Package weight | 5.47 kg |
| Packaging data | |
| Quick start guide | Yes |
| Mounting kit | Yes |
| Package width | 395 mm |
| Package depth | 395 mm |
| Package height | 197 mm |
| Package weight | 5.47 kg |
| Packaging content | |
| Quick start guide | Yes |
| Mounting kit | Yes |
| Quantity per pack | 1 pc(s) |
| Operational conditions | |
| Operating relative humidity (H-H) | 0 - 100% |
| Operating temperature (T-T) | -40 - 65 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Storage relative humidity (H-H) | 0 - 100% |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
