120.1 x 120.1 x 29.2 mm, -40 - 85C, 2.5W, 3000mA, 3 - 36VDC
Advantech BB-APXN-Q5420 wireless access point 100 Mbit/s Blue
£241.15
Taxes included.
Shipping calculated at checkout.
Details
Key Features
- Supports up to 9 Wi-Fi clients
- Advanced Enterprise Class wireless security (WPA2-Enterprise, WPA, WEP, EAP)
- External 5-36 VDC power source (not included, sold separately)
Description
Model APXN-Q5420 industrial wireless access point is built for networking equipment in an array of machine-to-machine (M2M) applications. The access point features industrial strength packaging and supports a wide temperature range (-40 to 85°C) to withstand challenging M2M environments. Combination Access Point and Client Capability - The AirborneM2M access point enables M2M equipment to create a self-sufficient Wi-Fi network and provides easy access to equipment data or resources from Wi-Fi enabled devices. The product also has the capability to be switched from an access point to a client; supporting both a single or dual RS-232/422/485 serial ports or a single 10/100 Mbps Ethernet port. The Ethernet port can be placed in either router or bridge mode. Dual-Band Wi-Fi - the access point establishes wireless connections over both 2.4 and 5 GHz bands. Whenever the 2.4 GHz airspace is overcrowded with competing wireless transmission, the access point can be switched to 5 GHz band to keep data flowing. Enterprise Class Security - Security protocols are important to mission critical wireless M2M applications. AirborneM2M access point multi-layer security addresses the requirements of Enterprise-class networks and corporate IT departments. These advanced security features include wireless security (802.11i/WAP2 enterprise), authentication security using WPA2 (AES-CCMP) and device security (multi-layered encryption). The access point includes a fully functional DHCP server to provide unique addresses for each authenticated client. Up to 10 clients can be supported on the local Wi-Fi network. External 5-36 VDC power source required (not included, sold separately)Specifications
| Data transmission | |
|---|---|
| Ethernet LAN data rates | 10,100 Mbit/s |
| Maximum data transfer rate | 100 Mbit/s |
| Performance | |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Spread spectrum method | DSSS, OFDM |
| Networking standards | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Maximum data transfer rate | 100 Mbit/s |
| Network | |
| Spread spectrum method | DSSS, OFDM |
| Networking standards | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Features | |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Spread spectrum method | DSSS, OFDM |
| Networking standards | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Maximum data transfer rate | 100 Mbit/s |
| Security | |
| Security algorithms | 64-bit WEP, 128-bit WEP, EAP, EAP-PEAP, EAP-TTLS |
| Power | |
| DC voltage range | 5 - 36 V |
| Design | |
| Product colour | Blue |
| Antenna | |
| Antenna type | External |
| Weight & dimensions | |
| Width | 120.1 mm |
| Depth | 120.1 mm |
| Height | 29.2 mm |
| Operational conditions | |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -40 - 85 °C |
| Storage temperature (T-T) | -40 - 85 °C |
