4-port RS-232/422/485 Serial Device Server
With COM port redirection mode, standard serial operation calls are transparently redirected to the EKI-1521, EKI-1522 and EKI-1524, guaranteeing compatibility with legacy serial devices and enabling backward compatibility with existing software. With TCP server, TCP client, and UDP modes, EKI- 1521, EKI-1522 and EKI-1524 ensure the compatibility of network software that uses a standard network API. Moreover, you can make serial devices communicate with other devices peer-to-peer, without any intermediate host PCs and software programming.
Advantech EKI-1524-CE serial server
£281.32
Taxes included.
Shipping calculated at checkout.
Details
Key Features
- Provides 2 x 10/100 Mbps Ethernet ports for LAN redundancy
- Provides COM port redirection (Virtual COM), TCP and UDP operation modes
- Supports up to 921.6 kbps, and any baud rate setting
- Allows a max. of 5 hosts to access one serial port
- Allows a max. of 16 hosts to be accessed as TCP client mode
- Built-in 15 KV ESD protection for all serial signals
- Provides rich configuration methods including Windows utility, Telnet console, and Web Browser
- Supports line to line 2 KV, line to ground 4 KV surge protection
Description
EKI-1521, EKI-1522 and EKI-1524 feature two independent Ethernet ports and MAC addresses to provide a redundant network mechanism to guarantee Ethernet network reliability. EKI-1521, EKI-1522 and EKI-1524 are serial device servers that connect RS-232/422/485 serial devices, such as PLC, meters, sensors, and barcode reader to an IP-based Ethernet LAN. They allow nearly any device with serial ports to connect and share an Ethernet network. EKI-1521, EKI-1522 and EKI-1524 provide various operations: COM port redirection (Virtual COMport), TCP Server, TCP Client and UDP mode.With COM port redirection mode, standard serial operation calls are transparently redirected to the EKI-1521, EKI-1522 and EKI-1524, guaranteeing compatibility with legacy serial devices and enabling backward compatibility with existing software. With TCP server, TCP client, and UDP modes, EKI- 1521, EKI-1522 and EKI-1524 ensure the compatibility of network software that uses a standard network API. Moreover, you can make serial devices communicate with other devices peer-to-peer, without any intermediate host PCs and software programming.
Specifications
| Technical details | |
|---|---|
| Stop bits | 1, 1.5, 2 |
| Flow Control type | RTS/CTS, XON/XOFF |
| Data bits | 5, 6, 7, 8 |
| Surge protection voltage | 4 kV |
| Serial ports quantity | 4 |
| RS-485 signals | Data+, Data-, GND |
| RS-422 signals | GND, RxD+, RxD-, TxD+, TxD- |
| RS-232 signals | CTS, DCD, DSR, DTR, GND, RI, RTS, RXD, TXD |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Isolation | 2.25 kV |
| Flow control support | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Electrostatic Discharge (ESD) protection | 15 kV |
| Baud rate | 921.6 Kbit/s |
| Parity bit | Even, Mark, No, Odd, Space |
| Compliance certificates | CE |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 2 |
| Cabling technology | 10/100Base-T(X) |
| Weight & dimensions | |
| Weight | 0.537 g |
| Dimensions (WxDxH) | 42 x 140 x 95 mm |
| Power | |
| Input current | 12 - 48 A |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 80 °C |
| Operating temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Security | |
| Security algorithms | HTTPS, SNMP |
| Indication | |
| LED indicators | LAN, Power, Speed, Status |
| Power LED | Yes |
| Link/Act LED | Yes |
| Software | |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1, Windows XP |
| Server operating systems supported | Windows Server 2003, Windows Server 2008, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Packaging content | |
| Wall mounting kit | Yes |
| Design | |
| International Protection (IP) code | IP30 |
| Housing material | Metal |
| Product colour | Black |
