480W @48Vdc, Industrial AC/DC power supply, DIN rail mount
The IE048-480 is a power supply delivering reliable 480W output power at 48Vdc; it was fully tested and validated to operate with Allied Telesis Industrial products.
Housed in compact metal case with DIN-rail clip, it takes special account of the mechanical robustness, electromagnetic compatibility and thermal characteristics to exhibit the required strengths to work satisfactorily in harsh environment where it will be exposed
Its highly efficient and stable output power has the capability to support 150% of peak load. The nominal output voltage of 48Vdc can be adjusted to match the application requirements.
The AC/DC rectifier operates over the full range of AC input voltage to fit worldwide power grids. The included active Power Factor Correction circuit (PFC) reduces energy costs by eliminating reactive power and harmonics from power lines. Besides the increment of efficiency, PFC is to comply with international regulations, which established limits on harmonic currents that can appear on the AC main line.
Allied Telesis AT-IE048-480-20 uninterruptible power supply (UPS) 480 W
Sale price
£202.35
Regular price
£370.00
Taxes included.
Shipping calculated at checkout.
Details
Key Features
- ۼ Electromagnetic immunity for industrial environments
- ۼ High efficiency
- ۼ Active PFC
- ۼ Stable output power with 150% peak current capability
- ۼ Wide input voltage range
- ۼ Protections: peak-current, over-current and over-temperature
- ۼ Remote ON/OFF
- ۼ Output power confirmation relay (DC_OK)
- ۼ Extended operating temperature range
- ۼ Air convention cooling
- ۼ Metal case
- ۼ DIN rail mount
Description
The ruggedized IE048-480 industrial power supply is a functional accessory for Allied Telesis products to build a solution suitable for Smart Cities (e.g. Surveillance & Security), Industrial Ethernet, Transportation or any application requiring systems that function in harsh environment with extended operating temperature.The IE048-480 is a power supply delivering reliable 480W output power at 48Vdc; it was fully tested and validated to operate with Allied Telesis Industrial products.
Housed in compact metal case with DIN-rail clip, it takes special account of the mechanical robustness, electromagnetic compatibility and thermal characteristics to exhibit the required strengths to work satisfactorily in harsh environment where it will be exposed
Its highly efficient and stable output power has the capability to support 150% of peak load. The nominal output voltage of 48Vdc can be adjusted to match the application requirements.
The AC/DC rectifier operates over the full range of AC input voltage to fit worldwide power grids. The included active Power Factor Correction circuit (PFC) reduces energy costs by eliminating reactive power and harmonics from power lines. Besides the increment of efficiency, PFC is to comply with international regulations, which established limits on harmonic currents that can appear on the AC main line.
Specifications
| Power | |
|---|---|
| Output power | 480 W |
| Input operation voltage (min) | 90 V |
| Input operation voltage (max) | 350 V |
| Output operation voltage (max) | 48 V |
| Maximum current | 15 A |
| Efficiency | 94% |
| Power factor | 0.98 |
| Performance | |
| LED indicators | Alarm, Status |
| Power protection features | Over current, Over voltage, Overheating |
| Features | |
| Output power | 480 W |
| Input operation voltage (min) | 90 V |
| Input operation voltage (max) | 350 V |
| Output operation voltage (max) | 48 V |
| Maximum current | 15 A |
| Efficiency | 94% |
| Power protection features | Over current, Over voltage, Overheating |
| Power factor | 0.98 |
| Input frequency | 50/60 Hz |
| Design | |
| Form factor | Tower |
| LED indicators | Alarm, Status |
| Product colour | White |
| Cooling type | Active |
| Housing material | Metal |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 20 - 90% |
| Storage relative humidity (H-H) | 20 - 90% |
| Technical details | |
| Harmonized System (HS) code | 8504.40.8500 |
| Compliance certificates | RoHS, WEEE |
| Certificates | |
| Compliance certificates | RoHS, WEEE |
| Cooling | |
| Cooling type | Active |
| Weight & dimensions | |
| Weight | 1.2 kg |
| Width | 70 mm |
| Height | 124 mm |
| Depth | 117 mm |
| Logistics data | |
| Export Control Classification Number (ECCN) | 5A992C |
| Harmonized System (HS) code | 8504.40.8500 |
| Other features | |
| Nominal output voltage | 48 V |
| Nominal input voltage | 90 - 264; 98 - 350 V |
