24" Full HD 1920 x 1080 LCD, 250 cd/m2, 25ms, Medical Display, USB hub, HDMI, DP, DVI, DVI, IP54, 583 x 386 x 66 mm, 75 kg
Advantech PDC-WP240 computer monitor 61 cm (24") 1920 x 1080 pixels Full HD LCD Blue, White
£851.43
Taxes included.
Shipping calculated at checkout.
Details
Key Features
- Wide 24" screen with Full HD 1920 x 1080 resolution
- Professional 2.3-megapixel color LCD monitor
- Pre-set DICOM, switchable to Gamma 2.2
- Supports USB hub function and AC power input
- Medical-grade device with IP54 rating
- PCAP touchscreen (optional)
Description
Clinical review monitors are designed for the needs of multi-tasking display services in a variety of medical imaging segments such as radiological modalities, surgical modalities, RIS, HIS, PACS, etc. Equipped with premium quality LCD panels and versatile image controller boards with a variety of connectivity, these clinical review monitors provide the users and system integrators multiple options and applications.Specifications
| Audio | |
|---|---|
| Built-in speaker(s) | Yes |
| Performance | |
| Built-in speaker(s) | Yes |
| Display | |
| Display brightness (typical) | 250 cd/m² |
| Screen shape | Flat |
| Display number of colours | 16.7 million colours |
| HD type | Full HD |
| Display technology | LCD |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Pixel pitch | 0.2745 x 0.2745 mm |
| Backlight type | LED |
| Display resolution | 1920 x 1080 pixels |
| Response time | 25 ms |
| Display diagonal | 61 cm (24") |
| Contrast ratio (typical) | 1000:1 |
| Touchscreen | No |
| Panel type | IPS |
| Multimedia | |
| Number of speakers | 2 |
| Built-in speaker(s) | Yes |
| Design | |
| Market positioning | Medical |
| Product colour | Blue, White |
| International Protection (IP) code | IP54 |
| Ports & interfaces | |
| Built-in USB hub | Yes |
| USB upstream port type | USB Type-B |
| Number of upstream ports | 1 |
| USB Type-A downstream ports quantity | 2 |
| DVI port | Yes |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Audio output | Yes |
| HDMI | Yes |
| Technical details | |
| Height (without stand) | 386 mm |
| Depth (without stand) | 66 mm |
| Width (without stand) | 583 mm |
| HDMI | Yes |
| Product colour | Blue, White |
| Power supply type | Internal |
| Touchscreen | No |
| Ergonomics | |
| VESA mounting | Yes |
| Panel mounting interface | 75 x 75,100 x 100 mm |
| Power | |
| Power supply type | Internal |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 1.3 A |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Packaging content | |
| Cables included | AC |
| Weight & dimensions | |
| Height (without stand) | 386 mm |
| Depth (without stand) | 66 mm |
| Width (without stand) | 583 mm |
| Weight (without stand) | 7.5 kg |
| Packaging data | |
| Cables included | AC |
| Other features | |
| Height (without stand) | 386 mm |
| Depth (without stand) | 66 mm |
| Width (without stand) | 583 mm |
| HDMI | Yes |
| Power supply type | Internal |
| Touchscreen | No |
