LCD Multi-function, 10.0kWatts / 10.0kVA, 230V, Hard Wire 3-wire, 600J, 76.5kg
APC Easy UPS On-Line SRV Ext. Runtime 10000VA 230V with External Battery Pack
High quality, Double-conversion On-line UPS designed for essential power protection needs even in the most unstable power conditions
Includes: CD with software, USB cable, User Manual
Automatic internal bypass
Supplies utility power to the connected loads in the event of a UPS power overload or fault.
Automatic restart of loads after UPS shutdown
Automatically starts up the connected equipment upon the return of utility power.
ECO Mode
Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection
EPO
Attach the device to an Emergency Power Off (EPO) system so that power can be turned off in an emergency situation.
Input power factor correction
Minimizes installation costs by enabling the use of smaller generators and cabling.
Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.
LCD graphics display
Text and mimic diagrams that display modes of operation, system parameters and alarms.
Serial connectivity
Provides management of the UPS via a serial port.
USB connectivity
Provides management of the UPS via a USB port (not available on all models).
APC SRV10KIL uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA 10000 W
Sale price
£3,487.51
Regular price
£5,027.69
Taxes included.
Shipping calculated at checkout.
Details
Description
SRV10KIL FeaturesAPC Easy UPS On-Line SRV Ext. Runtime 10000VA 230V with External Battery Pack
High quality, Double-conversion On-line UPS designed for essential power protection needs even in the most unstable power conditions
Includes: CD with software, USB cable, User Manual
Automatic internal bypass
Supplies utility power to the connected loads in the event of a UPS power overload or fault.
Automatic restart of loads after UPS shutdown
Automatically starts up the connected equipment upon the return of utility power.
ECO Mode
Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection
EPO
Attach the device to an Emergency Power Off (EPO) system so that power can be turned off in an emergency situation.
Input power factor correction
Minimizes installation costs by enabling the use of smaller generators and cabling.
Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.
LCD graphics display
Text and mimic diagrams that display modes of operation, system parameters and alarms.
Serial connectivity
Provides management of the UPS via a serial port.
USB connectivity
Provides management of the UPS via a USB port (not available on all models).
Specifications
| Power | |
|---|---|
| Output power | 10000 W |
| Input operation voltage (min) | 220 V |
| Input operation voltage (max) | 240 V |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
| Surge energy rating | 600 J |
| Emergency Power Off (EPO) | Yes |
| Crest factor | 3:1 |
| Output power capacity | 10 kVA |
| Performance | |
| UPS topology | Double-conversion (Online) |
| Waveform | Sine |
| LED indicators | Power, Status |
| Surge protection | Yes |
| Power protection features | Overload |
| Audible alarm(s) | Yes |
| Features | |
| UPS topology | Double-conversion (Online) |
| Waveform | Sine |
| Output power | 10000 W |
| Input operation voltage (min) | 220 V |
| Input operation voltage (max) | 240 V |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
| Surge energy rating | 600 J |
| Surge protection | Yes |
| Emergency Power Off (EPO) | Yes |
| Power protection features | Overload |
| Crest factor | 3:1 |
| Audible alarm(s) | Yes |
| Output power capacity | 10 kVA |
| Input frequency | 40/70 Hz |
| Ports & interfaces | |
| Emergency Power Off (EPO) connector | Yes |
| USB port | Yes |
| Serial interface | Yes |
| Serial interface type | RS-232 |
| SmartSlot | Yes |
| AC outlet types | Hard Wire 3-wire (1P + N + E) |
| RS-232 ports | 1 |
| Design | |
| Form factor | Tower |
| LED indicators | Power, Status |
| Product colour | Black |
| Cooling type | Active |
| Certification | CE, IEC 62040-1-1, IEC 62040-1-2 |
| Built-in fan | Yes |
| Display type | LCD |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 14763 m |
| Technical details | |
| Harmonized System (HS) code | 85078000 |
| Compliance certificates | RoHS |
| Certificates | |
| Certification | CE, IEC 62040-1-1, IEC 62040-1-2 |
| Compliance certificates | RoHS |
| Packaging content | |
| Cables included | USB cable |
| Manual | Yes |
| Cooling | |
| Cooling type | Active |
| Built-in fan | Yes |
| Weight & dimensions | |
| Weight | 76.5 kg |
| Width | 380 mm |
| Package weight | 82.5 kg |
| Height | 368 mm |
| Depth | 485 mm |
| Packaging data | |
| Cables included | USB cable |
| Manual | Yes |
| Package weight | 82.5 kg |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
