4x30W PoE, 289x289x227mm, 16kg, Aluminium
Axis 01535-001 network switch Fast Ethernet (10/100) Power over Ethernet (PoE) Aluminium
Sale price
£6,046.81
Regular price
£6,609.67
Taxes included.
Shipping calculated at checkout.
Details
Key Features
- ATEX, IECEx Ex d IIC/IIIC; Extends the camera’s temperature range; Four 30 W PoE-ports; Resistant to corrosion; Single-mode or multi-mode fiber variants
Description
Ex Connection Rail 4-Port PoE is a high performance PoE switch and 24 V DC power supply for hazardous areas. It is designed to connect explosion-protected network cameras over long distances. The network connection can be realized via optical fiber or copper-bound Ethernet, and is available for single-mode or multi-mode fiber. The power supply provides additional power to the cameras heater to extend the temperature range. The Ex d-rated enclosure is made from seawater-resistant copper-free aluminum and is ready for wall mounting.Specifications
| Ports & interfaces | |
|---|---|
| Copper ethernet cabling technology | 10BASE-T, 100BASE-FX, 100BASE-TX |
| Basic switching RJ-45 Ethernet ports quantity | 4 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Technical details | |
| Product colour | Aluminium |
| Housing material | Aluminium |
| Network | |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-FX, 100BASE-TX |
| Networking standards | IEEE 802.3at |
| 10G support | No |
| Certificates | |
| Certification | ATEX, IECEx, EAC |
| Design | |
| Product colour | Aluminium |
| Housing material | Aluminium |
| Certification | ATEX, IECEx, EAC |
| Performance | |
| Harmonized System (HS) code | 85176990 |
| Power | |
| Output voltage | 24 V |
| AC input voltage | 100 - 240 V |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 120 W |
| Power over Ethernet (PoE) | Yes |
| Operational conditions | |
| Storage temperature (T-T) | -60 - 50 °C |
| Operating temperature (T-T) | -60 - 50 °C |
| Operating relative humidity (H-H) | 10 - 100% |
| Weight & dimensions | |
| Width | 289 mm |
| Depth | 289 mm |
| Height | 227 mm |
| Weight | 16 kg |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
