60 mm, 8.3 fps, 24 V, H.264, M-JPEG, 512 MB RAM, 256 MB Flash, microSD, RJ-45, 557 x 229 x 289 mm
Axis 01122-001 security camera Bullet IP security camera 640 x 480 pixels Desk/Wall
MPN:
01122-001
Out of stock
Price excluding VAT:
Exc Vat £8,067.35
Price including VAT:
Inc Vat £9,680.82
Shipping calculated at checkout.
Details
Key Features
- Electronic image stabilization; Outstanding thermal contrast – 640x480 resolution; Reliable thermal detection; Responsive positioning with quick, smooth pan and tilt capabilities; Save bandwidth with Zipstream
Description
AXIS Q8642-E PT Thermal Network Camera offers outstanding thermal contrast and 10° field of view, which together with analytics, enables long-range detection and immediate visual confirmation for the operator. Highly responsive and reliable positioning camera, designed for continuous and jerk-free pan and tilt movements (360° endless and 135° from ground to sky). When column-mounted, it enables 360° unobstructed field of view, covering a wide area and reducing the cost for additional cameras. AXIS Q8642-E provides 640x480 thermal resolution, Zipstream and electronic image stabilization. Features both RJ45 and SFP interfaces, enabling a long-distance fiber connection with a failover network link.Specifications
| Performance | |
|---|---|
| Preset points | Yes |
| Number of languages | 11 |
| Languages support | Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Portuguese, Russian |
| Type | IP security camera |
| Connectivity technology | Wired |
| PTZ control | Yes |
| Certification | EN 55032 A, EN 55024, EN 61000-6-1, EN 61000-6-2, EN 61000-3-2, EN 61000-3-3, FCC 15 B A, VCCI A ITE, ICES-003 A, RCM AS/NZS CISPR 32 A, EN 50121-4, IEC 62236-4, IEC/EN/UL 62368-1, IEC/EN/UL 60950-22, IEC/EN 60529 IP66, NEMA 250 4X, IEC 60068–2–1, IEC 60068–2–2, IEC 60068–2–6, IEC 60068–2–27 |
| Design | |
| Form factor | Bullet |
| Product colour | White |
| Mounting type | Desk/Wall |
| International Protection (IP) code | IP66 |
| Housing material | Aluminium |
| Camera | |
| Tilt angle range | -90 - 45° |
| Tilt speed | 60 °/sec |
| Pan range | -180 - 180° |
| Pan speed | 120 °/sec |
| Lens viewing angle, horizontal | 10° |
| Lens system | |
| Maximum aperture number | 1.25 |
| Fixed focal length | 60 mm |
| Video | |
| Image quality adjustment | Brightness, Contrast, Sharpness |
| Image stabilizer | Yes |
| Video compression formats | H.264, M-JPEG |
| Maximum resolution | 640 x 480 pixels |
| Frame rate | 8.3 fps |
| Network | |
| Bluetooth | No |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Wi-Fi | No |
| Supported network protocols | IPv4/v6, HTTP, HTTPS , SSL/TLS , QoS L3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH |
| Storage | |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Internal memory | 512 MB |
| Flash memory | 256 MB |
| Ports & interfaces | |
| Terminal block port | Yes |
| Interface | RJ-45 |
| Connectivity technology | Wired |
| Security | |
| Alert notification type | E-mail, Snapshot alert message |
| Video motion detection | Yes |
| Management features | |
| Web-based management | Yes |
| Power | |
| Power source type | DC |
| Power over Ethernet (PoE) | No |
| DC output voltage | 24 |
| Certificates | |
| Certification | EN 55032 A, EN 55024, EN 61000-6-1, EN 61000-6-2, EN 61000-3-2, EN 61000-3-3, FCC 15 B A, VCCI A ITE, ICES-003 A, RCM AS/NZS CISPR 32 A, EN 50121-4, IEC 62236-4, IEC/EN/UL 62368-1, IEC/EN/UL 60950-22, IEC/EN 60529 IP66, NEMA 250 4X, IEC 60068–2–1, IEC 60068–2–2, IEC 60068–2–6, IEC 60068–2–27 |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 60 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 100% |
| Weight & dimensions | |
| Width | 229 mm |
| Depth | 289 mm |
| Height | 557 mm |
| Weight | 12.2 kg |
| Packaging content | |
| Number of cameras | 1 |
| User guide | Yes |
| Other features | |
| Video compression formats | H.264, M-JPEG |
| Logistics data | |
| Harmonized System (HS) code | 85258900 |
