Intel Xeon D-1531, 8 GB DDR4, 2.5/3.5" SATA, LAN, DiskStation Manager
Designed for businesses seeking large data storage capacity, RS3617RPxs is a high-performance, 12-bay rackmount NAS equipped with redundant power supplies, ensuring business continuity. Organizations can integrate seamlessly with virtualization solutions including VMware, Citrix, Hyper-V, and OpenStack Cinder.
High-performance NAS server
RS3617RPxs delivers stunning performance with over 3,829 MB/s sequential throughput and 433,873 IOPS under a RAID 5 configuration with 10GbE Link Aggregation. Equipped with 8GB DDR4 ECC RAM (upgradeable to 64GB), RS3617RPxs ensures data accuracy when handling high-value data and mission-critical tasks across large-scale businesses.
Scale on demand
As your data storage needs grow, RS3617RPxs can be connected to one or two dedicated RX1217/RX1217RP expansion units, allowing you to expand storage capacity up to 36 drives without disrupting service. The high-bandwidth cable ensures speedy data transmission between the main server and expansion unit.
10GbE network capability
In addition to the four built-in Gigabit ports, RS3617RPxs comes with two PCIe 3.0 x8 slots that allows for the installation of two 10GbE Network Interface Cards (NIC), maximizing bandwidth and meeting high performance requirements for data-intensive applications.
Reliable redundancy mechanisms
RS3617RPxs comes with comprehensive redundancy mechanisms to ensure business continuity. Built-in four LAN ports with failover provides reliable redundancy in the event of unexpected network failure. The high reliability system design, including fanless CPU heat-sink and passive cooling technologies, prevents a single point of failure. Other features such as redundant power supplies, system fans, and network ports with failover support ensure continual service uptime.
Synology RackStation RS3617RPxs NAS Rack (3U) Intel® Xeon® D D-1521 8 GB DDR4 HDD DiskStation Manager Black
MPN:
RS3617RPXS
Out of stock
Price excluding VAT:
Exc Vat £2,544.25
Price including VAT:
Inc Vat £3,053.10
Shipping calculated at checkout.
Details
Description
Reliable storage solution providing uninterrupted services for large-scale businessesDesigned for businesses seeking large data storage capacity, RS3617RPxs is a high-performance, 12-bay rackmount NAS equipped with redundant power supplies, ensuring business continuity. Organizations can integrate seamlessly with virtualization solutions including VMware, Citrix, Hyper-V, and OpenStack Cinder.
High-performance NAS server
RS3617RPxs delivers stunning performance with over 3,829 MB/s sequential throughput and 433,873 IOPS under a RAID 5 configuration with 10GbE Link Aggregation. Equipped with 8GB DDR4 ECC RAM (upgradeable to 64GB), RS3617RPxs ensures data accuracy when handling high-value data and mission-critical tasks across large-scale businesses.
Scale on demand
As your data storage needs grow, RS3617RPxs can be connected to one or two dedicated RX1217/RX1217RP expansion units, allowing you to expand storage capacity up to 36 drives without disrupting service. The high-bandwidth cable ensures speedy data transmission between the main server and expansion unit.
10GbE network capability
In addition to the four built-in Gigabit ports, RS3617RPxs comes with two PCIe 3.0 x8 slots that allows for the installation of two 10GbE Network Interface Cards (NIC), maximizing bandwidth and meeting high performance requirements for data-intensive applications.
Reliable redundancy mechanisms
RS3617RPxs comes with comprehensive redundancy mechanisms to ensure business continuity. Built-in four LAN ports with failover provides reliable redundancy in the event of unexpected network failure. The high reliability system design, including fanless CPU heat-sink and passive cooling technologies, prevents a single point of failure. Other features such as redundant power supplies, system fans, and network ports with failover support ensure continual service uptime.
Specifications
| Storage | |
|---|---|
| Storage drives installed | Yes |
| Installed storage drive type | HDD |
| Supported storage drive types | HDD & SSD |
| Number of storage drives supported | 12 |
| Storage drive interface | Serial ATA |
| Storage drive size | 2.5/3.5" |
| Hot-swap drive bays | Yes |
| RAID support | Yes |
| Supported file systems | BTRFS, ext4 |
| RAID levels | 0, 1, 5, 6, 10, JBOD |
| Processor | |
| Processor manufacturer | Intel |
| Thermal Design Power (TDP) | 45 W |
| Stepping | V2 |
| Scalability | 1S |
| Processor threads | 8 |
| Processor socket | BGA 1667 |
| Processor series | Intel Xeon D-1500 |
| Processor package size | 37.5 x 37.5 mm |
| Processor operating modes | 64-bit |
| Processor lithography | 14 nm |
| Processor codename | Broadwell |
| Processor code | SR2DF |
| Processor cache | 6 MB |
| Processor boost frequency | 2.7 GHz |
| PCI Express slots version | 2.0, 3.0 |
| PCI Express configurations | 1x16, 1x4, 1x8 |
| ECC supported by processor | Yes |
| CPU configuration (max) | 1 |
| Maximum internal memory supported by processor | 128 GB |
| Conflict-Free processor | Yes |
| Processor ARK ID | 91202 |
| Processor frequency | 2.4 GHz |
| Processor family | Intel® Xeon® D |
| Processor model | D-1521 |
| Processor cores | 4 |
| Memory | |
| Internal memory type | DDR4 |
| Internal memory | 8 GB |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Wi-Fi | No |
| Wake-on-LAN ready | Yes |
| Supported network protocols | CIFS, AFP, NFS, FTP, WebDA |
| iSCSI support | Yes |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 4 |
| Hard drive | |
| RAID support | Yes |
| Supported file systems | BTRFS, ext4 |
| RAID levels | 0, 1, 5, 6, 10, JBOD |
| Design | |
| Cooling type | Active |
| Fan diameter | 8 cm |
| Product colour | Black |
| Number of fans | 4 fan(s) |
| LED indicators | Yes |
| Chassis type | Rack (3U) |
| Technical details | |
| Type | NAS |
| Device class | Large Enterprise Business |
| Backup function | Yes |
| Backup features | iSCSI LUN |
| Product colour | Black |
| LED indicators | Yes |
| Chassis type | Rack (3U) |
| Number of fans | 4 fan(s) |
| Harmonized System (HS) code | 84714100 |
| Compliance certificates | RoHS |
| Performance | |
| Type | NAS |
| Device class | Large Enterprise Business |
| Backup function | Yes |
| Backup features | iSCSI LUN |
| Windows operating systems supported | Yes |
| Operating system installed | DiskStation Manager |
| Access Control List (ACL) | Yes |
| Cooling | |
| Cooling type | Active |
| Fan diameter | 8 cm |
| Number of fans | 4 fan(s) |
| Security | |
| Access Control List (ACL) | Yes |
| Software | |
| Windows operating systems supported | Yes |
| Operating system installed | DiskStation Manager |
| Power | |
| Power supply location | Built-in |
| Power supply unit (PSU) capacity | 500 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| Redundant power supply (RPS) support | Yes |
| Number of power supply units | 2 |
| Weight & dimensions | |
| Width | 430.5 mm |
| Depth | 692 mm |
| Height | 88 mm |
| Packaging content | |
| Cables included | AC |
| Processor special features | |
| UART | Yes |
| Thermal Monitoring Technologies | Yes |
| Maximum number of PCI Express lanes | 32 |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Secure Key | Yes |
| Intel® OS Guard | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel TSX-NI version | 1.00 |
| Intel TSX-NI | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel Secure Key Technology version | 1.00 |
| Intel Enhanced Halt State | Yes |
| Intel 64 | Yes |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Embedded options available | No |
| Memory channels supported by processor | Dual |
| Memory types supported by processor | DDR3-SDRAM, DDR4-SDRAM |
| System requirements | |
| Windows operating systems supported | Yes |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Logistics data | |
| Harmonized System (HS) code | 84714100 |
| Packaging data | |
| Cables included | AC |
| Other features | |
| Processor ARK ID | 91202 |
| Compliance certificates | RoHS |
