Enterprise Campus Aggregation, 6x 100/40G QSFP28 ports, 48x 25/10G SFP28 ports, 3.6 Tbps, 2.3 Bpps, 442.4 x 43.7 x 496 mm
Ubiquiti UniFi ECS-Aggregation Managed L2/L3 1U Grey
£3,306.70
Taxes included.
Shipping calculated at checkout.
Details
Description
1.8 Tbps high-density 100G/25G Layer 3 Etherlighting™ aggregation switch with MC-LAG support for high availability system design.Specifications
| Management features | |
|---|---|
| Switch type | Managed |
| Multicast support | Yes |
| Switch layer | L2/L3 |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports type | No |
| QSFP28 ports quantity | 6 |
| SFP28 ports quantity | 48 |
| Network | |
| VLAN support | Yes |
| Port mirroring | Yes |
| Number of VLANs | 1000 |
| Link aggregation | Yes |
| Flow control support | Yes |
| Broadcast storm control | Yes |
| 10G support | Yes |
| Network virtualization technologies | Multi-Chassis Link Aggregation (MLAG) |
| Virtual LAN features | Voice VLAN |
| IPv4 routes | 512000 |
| IGMP snooping | Yes |
| Data transmission | |
| Packet buffer memory | 24 MB |
| MAC address table | 256000 entries |
| Switching capacity | 3600 Gbit/s |
| Jumbo frames support | Yes |
| Forwarding rate | 2400 Mpps |
| Throughput | 1800 Gbit/s |
| Number of VLANs | 1000 |
| Security | |
| Loop protection | Yes |
| MAC address filtering | Yes |
| IGMP snooping | Yes |
| DHCP features | DHCP guarding, DHCP relay, DHCP snooping |
| Multicast features | |
| Multicast support | Yes |
| Design | |
| Display type | LCM |
| Form factor | 1U |
| Product colour | Grey |
| LED indicators | Yes |
| Housing material | SGCC |
| Rack mounting | Yes |
| Number of fans | 5 fan(s) |
| Redundant fans support | Yes |
| Power | |
| Power consumption (max) | 340 W |
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Number of power supply units | 2 |
| Power source | AC |
| Operational conditions | |
| Operating temperature (T-T) | -5 - 40 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Heat dissipation | 1160.08 BTU/h |
| Virtual LAN features | |
| VLAN support | Yes |
| Number of VLANs | 1000 |
| Virtual LAN features | Voice VLAN |
| Weight & dimensions | |
| Width | 442.4 mm |
| Depth | 496 mm |
| Height | 43.7 mm |
| Weight | 9.9 kg |
| Performance | |
| Packet buffer memory | 24 MB |
| Technical details | |
| Form factor | 1U |
| Product colour | Grey |
| Housing material | SGCC |
| Rack mounting | Yes |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) |
| Memory | |
| Packet buffer memory | 24 MB |
| Certificates | |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) |
| Indication | |
| LED indicators | Yes |
