15.6” PCAP 10pt touchscreen PC with Android, PoE Technology and iiSignage²
iiyama 15.6” PCAP 10pt touchscreen PC with Android, PoE Technology and iiSignage²
£248.58
Taxes included.
Shipping calculated at checkout.
Details
Reasons To Buy
Connectivity
The RJ45 (LAN) connector supporting Power over Ethernet technology (POE) allows to provide both data connection and power by a single cable, which simplifies installation in areas where many cables would interfere with the environment.Android OS
Thanks to Android OS, you can easily customize the display to your needs by installing applications directly to it.iiSignage²
iiSignage² is our digital signage content management platform to easily show and control your content and to manage your displays in a secure way. The Content Management System (CMS) gives you total control of your messaging and advertising remotely and safely.Description
The ProLite TW1623AS-B3P is a smart and intuitive 15.6" touch panel PC, designed for high-traffic environments such as meeting rooms, info points, or hospitality spaces. Its 10-point PCAP touch technology ensures smooth and precise interaction. Powered by Android 13, and equipped with powerful hardware, it allows easy installation of apps directly on the device - making it a all-in-one solution. Thanks to Power over Ethernet (PoE), both power and data are delivered through a single cable, simplifying installation and reducing additional cables. With a built-in microphone and speakers, the TW1623AS-B3P delivers seamless, modern interaction in any smart space. Additionally, it integrates effortlessly with iiSignage² , iiyama’s Content Management System (CMS), giving you full control over your messages and advertising, in landscape portrait and face-up position.Specifications
| Display | |
|---|---|
| HDCP | Yes |
| Display brightness (typical) | 450 cd/m² |
| Display number of colours | 16.7 million colours |
| Native aspect ratio | 16:9 |
| HD type | Full HD |
| Display technology | LED |
| Viewing angle, horizontal | 170° |
| Viewing angle, vertical | 170° |
| Pixel pitch | 0.1792 x 0.1792 mm |
| Viewable size, horizontal | 34.4 cm |
| Viewable size, vertical | 19.4 cm |
| Display resolution | 1920 x 1080 pixels |
| Response time | 30 ms |
| Display diagonal | 39.6 cm (15.6") |
| Contrast ratio (typical) | 1000:1 |
| Surface hardness | 6H |
| Touchscreen | Yes |
| Number of simultaneous touchpoints | 10 |
| Panel type | IPS |
| Colour depth | 8 bit |
| Display diagonal (metric) | 39.5 cm |
| Touchscreen technology | Projected capacitive system |
| Display brightness | 450 cd/m² |
| Response time measurement type | GTG (Gray to Gray) |
| Audio | |
| Built-in speaker(s) | Yes |
| RMS rated power | 4 W |
| Performance | |
| Built-in speaker(s) | Yes |
| RMS rated power | 4 W |
| Compatible memory cards | SD |
| Card reader integrated | Yes |
| Operating system installed | Android |
| Operating system version | 13 |
| Operating hours (hours/days) | 24/7 |
| Management features | |
| On Screen Display (OSD) | Yes |
| Network | |
| Ethernet LAN (RJ-45) ports | 1 |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| Multimedia | |
| Number of speakers | 2 |
| Built-in speaker(s) | Yes |
| RMS rated power | 4 W |
| Design | |
| Certification | CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA |
| Product colour | Black |
| Front bezel colour | Black |
| Glass thickness | 1.8 mm |
| Ports & interfaces | |
| USB version | 2.0 |
| HDMI ports quantity | 1 |
| HDCP | Yes |
| Audio input | Mini Jack |
| Microphone in | Yes |
| Compatible memory cards | SD |
| Card reader integrated | Yes |
| Mini HDMI ports quantity | 1 |
| USB Touch port | Yes |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Technical details | |
| Placement supported | Indoor |
| Compatible memory cards | SD |
| Card reader integrated | Yes |
| Product colour | Black |
| Front bezel colour | Black |
| Built-in processor | Yes |
| Power supply type | External |
| Active display area (W x H) | 344.2 x 193.6 mm |
| Multi-touch | Yes |
| Weight (with stand) | 1.5 kg |
| Surface hardness | 6H |
| Touchscreen | Yes |
| Number of simultaneous touchpoints | 10 |
| Ergonomics | |
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| On Screen Display (OSD) | Yes |
| Cable management | Yes |
| Power | |
| Power supply type | External |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 9 W |
| Power consumption (off) | 0.3 W |
| AC adapter output voltage | 12 V |
| Weight & dimensions | |
| Width (with stand) | 387 mm |
| Depth (with stand) | 30.5 mm |
| Height (with stand) | 244 mm |
| Weight (with stand) | 1.5 kg |
| Package width | 477 mm |
| Package depth | 477 mm |
| Package height | 298 mm |
| Package weight | 2.45 kg |
| Packaging data | |
| Package width | 477 mm |
| Package depth | 477 mm |
| Package height | 298 mm |
| Package weight | 2.45 kg |
| Quick start guide | Yes |
| Power adapter included | Yes |
| Packaging content | |
| Quick start guide | Yes |
| Power adapter included | Yes |
| Thin Client | |
| Operating system installed | Android |
| Processor cores | 4 |
| Processor frequency | 2 GHz |
| Processor family | ARM Rockchip |
| Processor model | RK3568 |
| Processor architecture | ARM Cortex-A55 |
| Other features | |
| Built-in processor | Yes |
| Active display area (W x H) | 344.2 x 193.6 mm |
| Multi-touch | Yes |
| USB ports quantity | 3 |
| Placement supported | Indoor |
| Certification | CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA |
| Ethernet LAN (RJ-45) ports | 1 |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
| Quick start guide | Yes |
| Surface hardness | 6H |
| Power supply type | External |
| Ethernet LAN | Yes |
| Touchscreen | Yes |
| Number of simultaneous touchpoints | 10 |
| Front bezel colour | Black |
| Certificates | |
| Certification | CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA |
