31.5” PCAP 10pt touchscreen PC with Android, PoE technology and iiSignage²
iiyama 31.5” PCAP 10pt touchscreen PC with Android, PoE technology and iiSignage²
£580.41
Taxes included.
Shipping calculated at checkout.
Details
Reasons To Buy
Connectivity
The RJ45 (LAN) connector supporting Power over Ethernet technology (POE) allows to provide both data connection and power by a single cable, which simplifies installation in areas where many cables would interfere with the environment.Android OS
Thanks to Android OS, you can easily customize the display to your needs by installing applications directly to it.iiSignage²
iiSignage² is our digital signage content management platform to easily show and control your content and to manage your displays in a secure way. The Content Management System (CMS) gives you total control of your messaging and advertising remotely and safely.Description
The ProLite TW3226AS-B3P is a smart and intuitive 31.5" Touch panel PC, designed for high-traffic environments such as meeting rooms, info points, or hospitality spaces. Its 10-point PCAP touch technology ensures smooth and precise interaction. Powered by Android 14, and equipped with powerful hardware, it allows easy installation of apps directly on the device - making it a all-in-one solution. Thanks to Power over Ethernet (PoE), both power and data are delivered through a single cable, simplifying installation and reducing additional cables. With a built-in quad microphone and 5W speakers, the TW3226AS-B3P delivers seamless, modern interaction in any smart space. Additionally, it integrates effortlessly with iiSignage² , iiyama’s Content Management System (CMS), giving you full control over your messages and advertising, in landscape portrait and face-up position.Specifications
| Display | |
|---|---|
| HDCP | Yes |
| Display brightness (typical) | 500 cd/m² |
| Display number of colours | 16.7 million colours |
| Native aspect ratio | 16:9 |
| HD type | Full HD |
| Display technology | LED |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Pixel pitch | 0.3637 x 0.3637 mm |
| Viewable size, horizontal | 69.8 cm |
| Viewable size, vertical | 39.3 cm |
| Display resolution | 1920 x 1080 pixels |
| Response time | 8 ms |
| Display diagonal | 80 cm (31.5") |
| Contrast ratio (typical) | 4000:1 |
| Surface hardness | 3H |
| Touchscreen | Yes |
| Number of simultaneous touchpoints | 10 |
| Panel type | VA |
| Colour depth | 8 bit |
| Display diagonal (metric) | 80.1 cm |
| Touchscreen technology | Projected capacitive system |
| Display brightness | 500 cd/m² |
| Response time measurement type | GTG (Gray to Gray) |
| Audio | |
| Built-in speaker(s) | Yes |
| RMS rated power | 10 W |
| Performance | |
| Built-in speaker(s) | Yes |
| RMS rated power | 10 W |
| Mean time between failures (MTBF) | 50000 h |
| Operating system installed | Android 14 |
| Flicker-free technology | Yes |
| Operating hours (hours/days) | 24/7 |
| Network | |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| Multimedia | |
| Number of speakers | 2 |
| Built-in speaker(s) | Yes |
| RMS rated power | 10 W |
| Design | |
| Certification | CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA |
| Product colour | Black |
| Front bezel colour | Black |
| Mean time between failures (MTBF) | 50000 h |
| Ports & interfaces | |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| DVI port | No |
| DC-in jack | Yes |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 0 |
| HDCP | Yes |
| Audio output | Mini jack |
| Microphone in | Yes |
| HDMI version | 1.4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB Touch port | Yes |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Technical details | |
| USB connector type | USB Type-A, USB Type-C |
| Placement supported | Indoor |
| Mean time between failures (MTBF) | 50000 h |
| Product colour | Black |
| Front bezel colour | Black |
| Built-in processor | Yes |
| Power supply type | External |
| Active display area (W x H) | 698.4 x 392.8 mm |
| Multi-touch | Yes |
| Weight (with stand) | 7.7 kg |
| Surface hardness | 3H |
| Touchscreen | Yes |
| Number of simultaneous touchpoints | 10 |
| Ergonomics | |
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Cable management | Yes |
| Power | |
| Power supply type | External |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 36.34 W |
| Power consumption (off) | 0.3 W |
| AC adapter output voltage | 12 V |
| Weight & dimensions | |
| Width (with stand) | 735 mm |
| Depth (with stand) | 35 mm |
| Height (with stand) | 436 mm |
| Weight (with stand) | 7.7 kg |
| Package width | 833 mm |
| Package depth | 833 mm |
| Package height | 508 mm |
| Package weight | 12.4 kg |
| Packaging data | |
| Package width | 833 mm |
| Package depth | 833 mm |
| Package height | 508 mm |
| Package weight | 12.4 kg |
| Quick start guide | Yes |
| Cables included | DC |
| Power adapter included | Yes |
| Packaging content | |
| Quick start guide | Yes |
| Cables included | DC |
| Power adapter included | Yes |
| Thin Client | |
| Operating system installed | Android 14 |
| Processor cores | 8 |
| Processor family | ARM Rockchip |
| Processor model | Rockchip RK3576 |
| Processor architecture | ARM Cortex-A53+Cortex-A72 |
| Other features | |
| Built-in processor | Yes |
| Active display area (W x H) | 698.4 x 392.8 mm |
| Multi-touch | Yes |
| USB ports quantity | 3 |
| USB connector type | USB Type-A, USB Type-C |
| Placement supported | Indoor |
| Mean time between failures (MTBF) | 50000 h |
| Certification | CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Quick start guide | Yes |
| Surface hardness | 3H |
| Power supply type | External |
| Ethernet LAN | Yes |
| Touchscreen | Yes |
| Number of simultaneous touchpoints | 10 |
| Front bezel colour | Black |
| Certificates | |
| Certification | CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA |
