15.6” Full HD PCAP 10pt touch screen with Android and POE Technology
iiyama 15.6” Full HD PCAP 10pt touch screen with Android and POE Technology
MPN:
TW1623AS-B1P
Low stock: 2
£317.48 GBP
VAT included.
Shipping calculated at checkout.
Details
Reasons To Buy
Connectivity
The RJ45 (LAN) connector supporting Power over Ethernet technology (POE*) allows to provide both data connection and power by a single cable, simplifying all installations. Together with the built-in microphone and speakers it offers interactive and almost limitless application possibilities. *Requires 30WAndroid OS
Thanks to Android OS, you can easily customize the display to your needs by installing applications directly to it.Touch technology - Capacitive
This technology uses a sensor-grid of micro-fine wires integrated into the glass that covers the screen. Touch is detected because electrical characteristics of the sensor grid change when human finger is placed on the glass. Thanks to the glass overlay this technology is highly durable, and the touch function remains unaffected even if the glass is scratched. It offers perfect picture performance and will work with human finger (also latex gloved) and stylus-pen.IPS Technology
IPS displays are best known for wide viewing angles and natural, highly accurate colours. They are especially suited for colour-critical applications.Anti-fingerprint coating
This special Nano coating ensures a smoother touch and less resistance in the swipe. It makes the screen less static and susceptible to dirt, dust, fingerprints and it improves the clarity of the content displayed on the screen.Description
The ProLite TW1623AS-B1P touch panel PC is a perfect choice for high-use environments such as retail, interactive POS, information desks or hospitality applications. Thanks to the pre-installed Android operating system, it is possible to easily customize the monitor by installing applications directly to it. The Power over Ethernet technology (POE) allows to provide both data connection and power by a single cable, simplifying all installations. This monitor can operate in landscape, portrait and face-up orientation in 24/7 operating time. Together with the built-in microphone and speakers it offers interactive and almost limitless application possibilities.Specifications
| Audio | |
|---|---|
| Built-in speaker(s) | Yes |
| RMS rated power | 4 W |
| Performance | |
| Built-in speaker(s) | Yes |
| RMS rated power | 4 W |
| Compatible memory cards | SD |
| Card reader integrated | Yes |
| Built-in microphone | Yes |
| Operating system installed | Android |
| Operating system version | 13 |
| Operating hours (hours/days) | 24/7 |
| Display | |
| Display brightness (typical) | 450 cd/m² |
| Display number of colours | 16.7 million colours |
| Native aspect ratio | 16:9 |
| HD type | Double Full HD |
| Viewing angle, horizontal | 170° |
| Viewing angle, vertical | 170° |
| Pixel pitch | 0.17925 x 0.17925 mm |
| Viewable size, horizontal | 34.4 cm |
| Viewable size, vertical | 19.4 cm |
| Display resolution | 1920 x 1080 pixels |
| Response time | 30 ms |
| Display diagonal | 39.6 cm (15.6") |
| Contrast ratio (typical) | 1000:1 |
| Surface hardness | 6H |
| Touchscreen | Yes |
| Number of simultaneous touchpoints | 10 |
| Panel type | IPS |
| Colour depth | 8 bit |
| Display diagonal (metric) | 39.5 cm |
| Touchscreen technology | Projected capacitive system |
| Display brightness | 450 cd/m² |
| Response time measurement type | GTG (Gray to Gray) |
| Management features | |
| On Screen Display (OSD) | Yes |
| Network | |
| Ethernet LAN (RJ-45) ports | 1 |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| Multimedia | |
| Number of speakers | 2 |
| Built-in speaker(s) | Yes |
| RMS rated power | 4 W |
| Built-in microphone | Yes |
| Design | |
| Certification | CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA |
| Product colour | Black |
| Front bezel colour | Black |
| Glass thickness | 1.8 mm |
| Ports & interfaces | |
| USB version | 2.0 |
| HDMI ports quantity | 1 |
| Audio input | Mini Jack |
| Microphone in | Yes |
| Compatible memory cards | SD |
| Card reader integrated | Yes |
| USB Touch port | Yes |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Technical details | |
| Placement supported | Indoor |
| Compatible memory cards | SD |
| Card reader integrated | Yes |
| Built-in microphone | Yes |
| Product colour | Black |
| Products per pallet | 150 pc(s) |
| Front bezel colour | Black |
| Pallet net width | 100 cm |
| Pallet net height | 120 cm |
| Pallet net length | 176 cm |
| Built-in processor | Yes |
| Power supply type | External |
| Active display area (W x H) | 344.2 x 193.6 mm |
| Multi-touch | Yes |
| Weight (with stand) | 1.5 kg |
| Surface hardness | 6H |
| Touchscreen | Yes |
| Number of simultaneous touchpoints | 10 |
| Ergonomics | |
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| On Screen Display (OSD) | Yes |
| Power | |
| Power supply type | External |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 24 W |
| Power consumption (off) | 0.3 W |
| AC adapter output voltage | 12 V |
| Weight & dimensions | |
| Width (with stand) | 387 mm |
| Depth (with stand) | 30.5 mm |
| Height (with stand) | 244 mm |
| Weight (with stand) | 1.5 kg |
| Package width | 477 mm |
| Package depth | 477 mm |
| Package height | 295 mm |
| Package weight | 2.4 kg |
| Packaging data | |
| Package width | 477 mm |
| Package depth | 477 mm |
| Package height | 295 mm |
| Package weight | 2.4 kg |
| Quick start guide | Yes |
| Package volume | 2400 cm³ |
| Power adapter included | Yes |
| Packaging content | |
| Quick start guide | Yes |
| Power adapter included | Yes |
| Thin Client | |
| Operating system installed | Android |
| Processor cores | 4 |
| Processor frequency | 2 GHz |
| Processor family | ARM Rockchip |
| Processor model | RK3568 |
| Processor architecture | ARM Cortex-A55 |
| Other features | |
| Built-in processor | Yes |
| Active display area (W x H) | 344.2 x 193.6 mm |
| Multi-touch | Yes |
| USB ports quantity | 3 |
| Placement supported | Indoor |
| Certification | CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA |
| Ethernet LAN (RJ-45) ports | 1 |
| Package volume | 2400 cm³ |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
| Quick start guide | Yes |
| Surface hardness | 6H |
| Power supply type | External |
| Ethernet LAN | Yes |
| Touchscreen | Yes |
| Number of simultaneous touchpoints | 10 |
| Products per pallet | 150 pc(s) |
| Front bezel colour | Black |
| Certificates | |
| Certification | CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA |
| Logistics data | |
| Products per pallet | 150 pc(s) |
| Pallet net width | 100 cm |
| Pallet net height | 120 cm |
| Pallet net length | 176 cm |
